New/Used: Used
Make: Ditch Witch
Model: JT30 All Terrain
Year Model: 2015
Inner Hours: 460 approx.
Outer Hours: 1483 approx.
Category: Horizontal Directional Drilling
Sub Category: Directional Drills
Engine: Cummins
Gross Horsepower: 130 hp
Engine: RPM 2,250
Thrust/Pullback: 13,390kgs
Maximum Spindle Torque: 4,000ft/lbs
Mud Pump: 50gpm at 42 Viscosity
Weight: 8 418 kg
Equipment Width: 2.26 m
Length: 5.61 m
Tooling: 158m AT Drill Pipe, 165m JT Drill Pipe, Pipe Boxes (AT & JT), Con Kit, JT Drill Head and Rockmaster Drill Head Assembly
New/Used: Used
Make: Toro
Model: DD 40-45
Year Model: 2016
Hours: 2,123
Category: Horizontal Directional Drilling
Sub Category: Directional Drills
Engine: Cummins
Gross Horsepower: 160 hp
Engine: RPM 2,300
Thrust/Pullback: 18 Tonnes
Maximum Spindle Torque: 4,500 ft-lbs
Mud Pump: 70 gpm
Weight Transport - No pipe baskets: 7,920 kg
Equipment Width: 2.16 m
Equipment Height: 2.19 m
Length: 3.05 m
Tooling: 55pcs of Forged Pipe, Drill Head & Starter Bar
New/Used: Used
Make: Vermeer
Model: S925TX
Year Model: 2021
Hours Approx: 185
Category: Stand-On Skid Steer
Sub Category: Mini Skid Steer
Engine: Kubota V1505
Fuel Type: Diesel
Gross Horsepower: 25 hp
Hydraulic System Flow: 12 gpm
Ground clearance: 15.2 cm
Weight (With no bucket): 1490 kgs
Height (to hinge pin): 214.6 cm
Equipment Width: 101.6cm
Equipment Height: 147.3 cm
Length: 213.4 cm
New/Used: Used Make Ditch Witch Model RT115 with H952 Trencher Plough Combo attachment
Year Model: 2005
Hours: Approx 1,452
Category: Trencher
Sub Category: Ride on Trencher and Plough
Engine: John Deere 4045FT150
Gross Horsepower: 115 hp
Weight: 3620 kg
Equipment Width: 2.1 m
Equipment Height: 2.82 m
Length: 3.7 m
Additional Attachments
Plow Dimensions:
Cover depth: 920 mm
Operating weight without boom,chain, or plow blade: 1300 kg
Transport length 2.62 m
Trencher dimensions:
Trench depth: 1.78 m
Trench width 150-300 mm
Angle of departure 22°
Transport length 3.2 m
Backfill Blade:
Blade Width: 2.03 m
Blade Height: 430 mm
Lift Height, above ground: 530 mm
Blade Drop, below ground: 280 mm
Tilt Angle, up/down: 24°
New/Used: Used
Make: American Auger
Model: DD-110S
Year: Model 2015
Hours: Approx 6 150
Category: Horizontal Directional Drilling
Sub Category: Directional Drills
Engine: Cummins
Gross Horsepower: 260 hp
Engine: RPM 2,200
Thrust/Pullback: 50 Tonnes
Maximum Spindle Torque: 15,000 ft -lb
Mud Pump: 200 gmp
Weight
Transport - No pipe baskets: 19, 051 kg
Equipment Width: 2.5 m
Equipment Height: 3 m
Length: 10.84 m
Comes With: On Board crane
Tooling: 414 meters (90pcs) of Forged Drill
Pipe 4.6m,
10 x Pipe Boxes & Drill Head
New/Used: Used
Make: Ditch Witch Model JT40
Year Model: 2017
Hours: Approx 3,335
Category: Horizontal Directional Drilling
Sub Category: Directional Drills
Engine: Cummins
Gross Horsepower: 160 hp
Engine RPM: 2,300
Thrust/Pullback: 17,850kgs
Maximum Spindle Torque: 5,500 ft/lbs
Mud Pump: 70 gpm
Weight: 13 500 kgs
Equipment Width: 2.26 m
Equipment Height: 2.46 m
Length: 7.37m
Equipment comes with 184m of JT Forged Drill Pipe (40 x 4.6m), Tall Pipe Box, Starter Bar & Drill Head
New/Used: Used
Make: American Auger Model DD-240T
Year Model: 2018
Hours: 450
Category: Horizontal Directional Drilling
Sub Category: Directional Drills
Engine: MTU (Mercedes)
Gross Horsepower: 523 (390 kW)
Engine: RPM 1900
Thrust/Pullback: 120 Tonnes
Maximum Spindle Torque: 43,900 ft. lbs
Mud Pump: No
Weight Transport - No pipe baskets: 38,373 kg
Equipment Width: 2.5 m
Equipment Height: 3.37 m
Length: 15.08 m
Tooling and Equipment Includes 680 meters of Range 2 NC50 4.5” IF 9.6m Drill Pipe. 10-12 pcs of Variety of Fly Cutter Reamers & Barrel Reamers (3pcs Reamers unused) Support Frame with steps for Operators Cabin (For better visibility). Kinshofer Pipehandler
New/Used: Used
Model: Perforator PBA85V Thrust Boring Machine
Year: 2015
Main Components:
- PBA85V Thrust Boring Machine
- HS90 Hydraulic Power pack
- HP Hose Set for HS90 x 20m
- BMA1000 1,000 ltr Flushing pump & tank
- Water Swivel for 114,3mm Pilot Rods
- Water Swivel Drive for Augers
For full details & more images download PDF: Pre-Owned Perforator PBA85V Thrust Boring Machine
